Low Battery Notifications
This script checks all devices for low battery levels every hour and sends notifications to the AWTRIX3 device for devices below 20%.
| System | Domoticz |
|---|---|
| Firmware | AWTRIX 3 |
| Topic | Smarthome |
| Built by | Galadril |
| File | gkVBAnn7An4x.json · 2.4 KB |
| Icons | — |
| Published | 9 Jan 2025 |
| Downloads | 4 |
⚙️ Script Activation:
The script is active by default, as indicated by active = true.
⏰ Trigger:
The script runs every hour, as specified by the timer:
timer = { 'every 1 hours' }.
📝 Logging:
Uses the logging level domoticz.LOG_INFO, with entries marked by "AWTRIX3_BATTERY" for easy identification.
🚀 Execution:
When triggered, the script performs the following actions:
🔍 Condition Check:
- Filters devices with a battery level below 20%.
- Ignores devices without a battery attribute or those with invalid battery readings.
🔄 Action:
- Sends notifications for devices with low battery levels:
- Battery < 20%: Uses a specific icon (ICON_BATTERY_20) and sends a warning.
- Battery < 10%: Uses a critical icon (ICON_BATTERY_10) and sends a critical warning.
- Formats the notification as a JSON payload containing the device name and icon.
- Sends the payload to the "AWTRIX3 - Send Notification" device:
- ✅ If the AWTRIX3 device is found: Sends the notification.
- 🛑 If the AWTRIX3 device is not found: Logs an error.
More information:
Domoticz: www.domoticz.com
Domoticz AWTRIX3 Plugin: https://github.com/galadril/Domoticz-AWTRIX3-Plugin
gkVBAnn7An4x.json
local BATTERY_THRESHOLD_1 = 20 -- First threshold for notification
local BATTERY_THRESHOLD_2 = 10 -- Second threshold for critical notification
local ICON_BATTERY_20 = 6355 -- Icon for battery level < 20%
local ICON_BATTERY_10 = 6354 -- Icon for battery level < 10%
return {
active = true,
on = {
timer = {
'every 1 hours'
}
},
logging = {
level = domoticz.LOG_INFO,
marker = "AWTRIX3_BATTERY"
},
execute = function(domoticz)
-- Filter devices with low battery level
local lowOnBattery = domoticz.devices().filter(function(device)
local level = device.batteryLevel
return (
level ~= nil and -- Ensure the device has a battery level attribute
level ~= 255 and -- Ignore if no battery measurement is applicable
level < BATTERY_THRESHOLD_1 -- Notify if below 20%
)
end)
-- Send individual notifications for each device with low battery
lowOnBattery.forEach(
function(lowDevice)
local batteryLevel = lowDevice.batteryLevel
local notificationIcon = nil
-- Determine the appropriate icon based on battery level
if batteryLevel < BATTERY_THRESHOLD_2 then
notificationIcon = ICON_BATTERY_10
else
notificationIcon = ICON_BATTERY_20
end
local message = lowDevice.name .. " low"
local payload = {
text = message,
icon = notificationIcon
}
local payloadJSON = domoticz.utils.toJSON(payload)
domoticz.log('Low battery warning for: ' .. message, domoticz.LOG_INFO)
domoticz.log("Sending to AWTRIX3: " .. payloadJSON, domoticz.LOG_INFO)
-- Send the notification to AWTRIX3
local awtrixDevice = domoticz.devices('AWTRIX3 - Send Notification')
if awtrixDevice then
awtrixDevice.setDescription(payloadJSON)
awtrixDevice.switchOn().afterSec(2)
else
domoticz.log("AWTRIX3 - Send Notification device not found", domoticz.LOG_ERROR)
end
end
)
end
}
