# @name EcoTrackerMonitor
# @desc Stromverbrauch+Zählerstände eines EcoTracker IR von Everhome
# @author Töm (taschenserver im Discord)
# @version 0.2
# @config ecotracker_ip text "EcoTracker Netzwerkadresse/IP-Adresse" default=ecotracker.local maxlen=253
# @config refreshrate number "Datenaktualisierungrate" default=5 min=2 max=600 unit=Sek.
# @config duration number "Anzeigedauer" default=5 min=1 max=600 unit=Sek.
# @config hold_powercounter number "Zählerstand-/WLAN-Infos Dauer (mittlere Taste)" default=10 min=2 max=600 unit=Sek.
# @config max_cons number "Max. Stromverbrauch pro Phase" default=3600 min=0 max=3600 unit=Watt
# @config max_feed_in number "Max. Einspeisung pro Phase" default=3600 min=0 max=3600 unit=Watt
# @config WiFi_signal_strength bool "Indikator WLAN-Signalstärke anzeigen" default=true
# @config power_consumption color "Stromverbrauch" default=0xFF0000
# @config power_feed_in color "Einspeisung" default=0x00FF00
# @config zero_power_consumption color "0-Verbrauch" default=0x666666

class EcoTrackerMon
  var url, ssid
  var durationMs, power, rssi, ticks, maxticks, eStatticks, holdStat, max_cons, max_feed_in, hc, busel
  var phases
  var pc, pf, p0
  var eCO, eCI, eCI1, eCI2
  var wifiInd

  def _color_from_value(value)
    var m = self.max_cons
    var c = self.pc
    if value < 0
      value = -value
      m = self.max_feed_in
      c = self.pf
    end
    if value > m value = m end
    if value == 0
      value = int(self.p0)
    else
      var f = 0.30 + 0.70 * (real(value) / m)
      var r = int(((c >> 16) & 0xFF) * f)
      var g = int(((c >> 8)  & 0xFF) * f)
      var b = int(( c        & 0xFF) * f)
      value = (r << 16) | (g << 8) | b
    end
    return value
  end

  def init()
    self.url    = "http://"+store.get("ecotracker_ip", "192.168.178.99")+"/v1/json"
    self.durationMs = store.get("duration",5)*1000
    self.power  = nil
    self.rssi   = nil
    self.ssid   = nil
    self.phases = [0,0,0]
    self.maxticks = store.get("refreshrate",5)
    self.max_cons = store.get("max_cons",3600)
    self.max_feed_in = store.get("max_feed_in",3600)
    self.pc = store.get("power_consumption",0xFF0000)
    self.pf = store.get("power_feed_in",0x00FF00)
    self.p0 = store.get("zero_power_consumption",0x666666)
    self.wifiInd = store.get("WiFi_signal_strength",true)
    self.ticks = 0
    self.busel = 0
    self.eStatticks = 0
    self.hc = store.get("hold_powercounter",10)
  end

  def on_body(body, status)
    if status == 401 log("token rejected") return end
    if body == nil return end
    m = re.search("\"power\":\\s*(-?\\d+)", body)
    if m != nil self.power = num(m[1]) end
    m = re.search("\"rssi\":\\s*(-?\\d+)", body)
    if m != nil self.rssi = num(m[1]) end
    m = re.search("\"ssid\":\\s*\"([^\"]*)\"", body)
    if m != nil self.ssid = m[1] end
    m = re.search("\"powerPhase1\":\\s*(-?\\d+)", body)
    if m != nil self.phases[0] = num(m[1]) end
    m = re.search("\"powerPhase2\":\\s*(-?\\d+)", body)
    if m != nil self.phases[1] = num(m[1]) end
    m = re.search("\"powerPhase3\":\\s*(-?\\d+)", body)
    if m != nil self.phases[2] = num(m[1]) end

    m = re.search("\"energyCounterOut\":\\s*(-?\\d+)", body)
    if m != nil self.eCO = round(real(m[1])/1000,1) end
    m = re.search("\"energyCounterIn\":\\s*(-?\\d+)", body)
    if m != nil self.eCI = round(real(m[1])/1000,1) end
    m = re.search("\"energyCounterInT1\":\\s*(-?\\d+)", body)
    if m != nil self.eCI1 = round(real(m[1])/1000,1) end
    m = re.search("\"energyCounterInT2\":\\s*(-?\\d+)", body)
    if m != nil self.eCI2 = round(real(m[1])/1000,1) end
  end

  def duration()
    return self.durationMs
  end

  def loop()
    if self.ticks <= 0
      self.ticks = self.maxticks
      http.get(self.url, / b, st -> self.on_body(b, st))
    end
    self.ticks -= 1
    if self.eStatticks <= 0
      self.busel = 0
    else
      self.eStatticks -= 1
    end
  end

  def draw()
    var t, tcolor
    clear()

# Powercounter
    if self.busel == 1
      t = ["","","","","","","",""]
      t[0] = "1.8.0: "
      t[1] = str(self.eCI)+" kWh"
      if self.eCI1 != nil
        t[2] = "  1.8.1: "
        t[3] = str(self.eCI1)+" kWh"
      end
      if self.eCI2 != nil
        t[4] = "  1.8.2: "
        t[5] = str(self.eCI2)+" kWh"
      end
      t[6]="  2.8.0: "
      t[7]=str(self.eCO)+" kWh"
      scroll_text([[t[0],0xAAAAAA],[t[1],0xFFFFFF],[t[2],0xAAAAAA],[t[3],0xFFFFFF],[t[4],0xAAAAAA],[t[5],0xFFFFFF],[t[6],0xAAAAAA],[t[7],0xFFFFFF]],0xFFFFFF,{"mode":"loop","gap":8,"repeat":10})
      return
    end
# WIFI-Info
    if self.busel == 2
      t = ["","",""]
      if self.rssi != nil t[0] = str(self.rssi)+" dbm" end
      if self.ssid != nil
        t[1] = "  SSID: "
        t[2] = self.ssid
      end
      scroll_text([["WIFI: ",0xAAAAAA],[t[0],0xFFFFFF],[t[1],0xAAAAAA],[t[2],0xFFFFFF]],0xFFFFFF,{"mode":"loop","gap":8,"repeat":10})
      return
    end
# Power
    if self.power == nil
  	  icon("40562", 0, 0)
 	    tcolor = 0xFF0000
 	    t = "OFF"
    else
      t = str(self.power)
      if self.power > -10000 && self.power < 10000 t = t+"W" end
      if self.power == 0
        icon("55398", 0, 0)
        tcolor = self.p0
      elif self.power < 0
        icon("52648", 0, 0)
    	  tcolor = self.pf
      else
        icon("52715", 0, 0)
        tcolor = self.pc
      end
    end

    var w = text_ink_width(t)
    text(8+((width()-8 - w) / 2), 6, t, tcolor)
# Phases
    for x : 0 .. 2
      if self.phases[x] != nil
        tcolor = self._color_from_value(self.phases[x])
        line((10+(x*7)),7,(14+(x*7)),7, tcolor)
      end
    end
# WIFI
    if self.wifiInd == true
      if self.rssi == nil || self.rssi < -79 # WLAN db
        pixel(0, 0, 0xFF0000)
      elif self.rssi < -69
        pixel(0, 0, 0xFFFF00)
      end
    end
  end

  def on_button(btn)
    if btn == "select"
      self.ticks = 0
      self.busel += 1
      if self.busel > 2 self.busel = 0 end
      self.eStatticks = self.hc
    end
  end
end

return EcoTrackerMon()
