Flow Details
Uses HTTP requests to the clock to power the clock up/down.
- The AWTRIX IP needs to be set through the environment variable.
- The power up/down times can be changed inside of the flow
[
{
"id": "0af138c02a817f4d",
"type": "tab",
"label": "AWTRIC Power Schedule",
"disabled": false,
"info": "",
"env": [
{
"name": "AWTRIX_IP",
"value": "192.168.0.98",
"type": "str"
}
]
},
{
"id": "492b8a8feabc6a31",
"type": "http request",
"z": "0af138c02a817f4d",
"name": "Power up",
"method": "POST",
"ret": "txt",
"paytoqs": "ignore",
"url": "",
"tls": "",
"persist": false,
"proxy": "",
"insecureHTTPParser": false,
"authType": "",
"senderr": true,
"headers": [
{
"keyType": "other",
"keyValue": "ContentType",
"valueType": "other",
"valueValue": "raw"
}
],
"x": 620,
"y": 400,
"wires": [
[]
]
},
{
"id": "67165c4287877f8d",
"type": "inject",
"z": "0af138c02a817f4d",
"name": "Morning Trigger",
"props": [
{
"p": "payload"
},
{
"p": "url",
"v": "AWTRIX_IP",
"vt": "global"
}
],
"repeat": "",
"crontab": "00 06 * * *",
"once": false,
"onceDelay": 0.1,
"topic": "",
"payload": "{\"power\": true}",
"payloadType": "str",
"x": 230,
"y": 400,
"wires": [
[
"59941d49c7ee6b4f"
]
]
},
{
"id": "14f1d17d156fd888",
"type": "http request",
"z": "0af138c02a817f4d",
"name": "Power down",
"method": "POST",
"ret": "txt",
"paytoqs": "ignore",
"url": "",
"tls": "",
"persist": false,
"proxy": "",
"insecureHTTPParser": false,
"authType": "",
"senderr": true,
"headers": [
{
"keyType": "other",
"keyValue": "ContentType",
"valueType": "other",
"valueValue": "raw"
}
],
"x": 630,
"y": 560,
"wires": [
[]
]
},
{
"id": "e96da971626c4e18",
"type": "inject",
"z": "0af138c02a817f4d",
"name": "Evening Trigger",
"props": [
{
"p": "payload"
}
],
"repeat": "",
"crontab": "00 22 * * *",
"once": false,
"onceDelay": 0.1,
"topic": "",
"payload": "{\"power\": false}",
"payloadType": "str",
"x": 220,
"y": 560,
"wires": [
[
"077e098f737dc41e"
]
]
},
{
"id": "077e098f737dc41e",
"type": "function",
"z": "0af138c02a817f4d",
"name": "Construct URL",
"func": "msg.url = \"http://\" + env.get(\"AWTRIX_IP\") + \"/api/power\";\n\nreturn msg;",
"outputs": 1,
"timeout": 0,
"noerr": 0,
"initialize": "",
"finalize": "",
"libs": [],
"x": 420,
"y": 560,
"wires": [
[
"14f1d17d156fd888"
]
]
},
{
"id": "59941d49c7ee6b4f",
"type": "function",
"z": "0af138c02a817f4d",
"name": "Construct URL",
"func": "msg.url = \"http://\" + env.get(\"AWTRIX_IP\") + \"/api/power\";\n\nreturn msg;",
"outputs": 1,
"timeout": 0,
"noerr": 0,
"initialize": "",
"finalize": "",
"libs": [],
"x": 440,
"y": 400,
"wires": [
[
"492b8a8feabc6a31"
]
]
}
]
-- Flow first published on September 23, 2025.
